WineMaster WINE C50SRX Conditioning Unit

The WineMaster C50SRX provides cellar cooling, heating, and compressor anti-frost features and utilizes the newest refrigerant in its system, as denoted by the X in its name.
  • Single Point Of Contact

    Our prominent attribute involves offering a singular point of contact for all aspects of project support, sales, warranty, and repairs.

  • Price Match Promise

    We promise to match the price offered by any dealer.

  • Warranty

    2 Years UK based warranty provided directly by us, without any involvement of third parties.

  • Reviews

    Our reputation is of utmost importance. We invite you to peruse our reviews on Trustpilot to gain insight into the experiences of our customers.

The WineMaster C50SR, similar to the C50S, provides additional protection through the antifrost-heating belt protector. This safeguard prevents the refrigerant oil of the compressor from freezing in low temperatures and preserves its liquid state, enabling the device to start smoothly.

Wine Master C50SR Manual

When purchasing Wine Master units from Elextric Ltd, you can benefit from a product warranty, outstanding customer service, and a single point of contact for any enquiries. View/download the Wine Master C50SR manual Here

Handy Tips
Greetings, thank you for taking the time to view this section. I’m Michel, the Managing Director and Lead Engineers at Elextric Ltd, and I have chosen to share my expertise with architects, contractors, and the self-proclaimed wine connoisseurs out there. My knowledge comes from a number of years of managing environment control management projects, one of which was centred around wine storage.

For your convenience, I have put together this checklist, acquired from prior assignments and accumulated years of experience, to assist in your pursuit of a flawlessly designed wine storage system.


– Sealed environment: When describing the importance of cellar insulation to my clients, I often use the term sealed environment. Same as a cold room or a fridge, creating a fully-enclosed area with insulated walls, ceiling, floor, and door will construct a tightly-sealed environment. I recommend using XPS insulation materials for this task.

– Wine Racking: I would recommend the racking per hole, as it allows the entire bottle to reach the ideal temperature and promotes air circulation within the cellar. Ultimately, however, the decision is up to the client.

– Unit location:  The Winemaster is reliant upon air circulation for its function, and thus it is highly advised to locate the unit as centrally as possible.

– Water drainage: When planning for the draining of condensation water, one should keep in mind that water always follows the laws of gravity. If the pipe length is too long, a condensation pump may be used as a viable solution.

– Operation temperature: This is related to the hot side of the unit (The compressor side) where the heat exchange is happening. For example, if the heat exchange happens within a plant room or utility room and the ambient temperature exceeds 30°c, an MHRV Mechanical Heat Recovery Ventilation system must be used.

Planning ahead is key to determining which wine conditioning unit to install. Then, design your cellar around the unit to ensure that both the electrical connection and the unit are within easy access.

I will update this section regularly based on my interactions with customers. If you have any queries or need help, please don’t hesitate to contact me through the enquiry form.

Payment & Security

winemaster c50sr, WINE C50SR, C50SR, winemaster c50srx, c50srx

Rest assured that your payment information is processed with the utmost security. We take measures to ensure that credit card details are not stored and that we do not have access to this sensitive information.

In stock, ready for despatch.
Delivery is usually within 3-5 working days.

£4,920.00 Inc. VAT & Delivery

We're Here To Help

Wine Enquiries

Looking for help in choosing the right product, setting up in your wine cellar, or scheduling a service visit? Simply fill out our contact form, and our team will get in touch with you shortly to discuss your requirements.

Strictly no marketing or offering service enquiries

MonoBlock Units

Winemaster C25 C50 ARM15
The Winemaster C25 models represent state-of-the-art wine conditioning units that can be conveniently installed from within your cellar. On the other hand, The Winemaster C50 models are designed for external mounting. If you opt for The Winemaster ARM15, it will need to be mounted on your ceiling and properly ventilated using ducting. Models marked with the letter S offer a built-in heating feature for climate control, while those labeled with R come with a compressor featuring anti-frost protection. Moreover, all Wine Masters are now equipped with the latest eco-friendly refrigerant, identified by the letter X. The cooling capacity, measured in cubic meters (m3), is clearly indicated by the numbers assigned to each model.

Ducting Units

Winemaster IN50 IN25
The Winemaster IN50 and IN25 are advanced ducting systems. The IN50 is designed to cover 50 cubic meters of cooling volume, while the IN25 covers 25 cubic meters. These systems must be installed inside the cellar and utilize insulating ducting pipes for efficient ventilation. Now, all Wine Masters come with the latest environmentally friendly refrigerant, identified with the letter X.

Split Units

Winemaster SP40 SP100
The SP40 can cool an impressive 40 cubic meters, while the SP100 can handle up to 100 cubic meters. The SP40 offers three models for different installation needs: CE for ceiling mounting, DU for ducting installation, and CA for cabinet installation. On the other hand, the SP100 also comes in three models with varying pipe lengths between the two units: 4.5 meters, 8 meters, and 15 meters.

Dust Filter & Replacement Parts

For All WineMaster Range
Discover our wide range of Winemaster dust filters and replacement parts. Our team also offers personalized service visits to maximize system performance and troubleshoot any issues.

WineMaster C50SRXCooling, Heating, And Compressor Anti-Frost
WineMaster C50SRXCooling, Heating, And Compressor Anti-Frost

The WineMaster C50SR possesses all of the qualities of the Winemaster C50S, with the addition of an antifrost-heating belt protector for the compressor. This special heating belt prevents the oil (refrigerant) in the unit from condensing in colder climates, thus assuring that the machine will be able to start up as usual. The heat from the belt helps the oil warm up, ensuring that it remains in a liquid state and can be used to initiate the device.

The features and benefits of the WineMaster C50SR include:

  • Wine protection from excessive light with a built-in night light
  • Easy installation with its wooden set-in frame
  • Large numbers of wines can be stored with the Wine master C50SR cooling 50m³
  • The best wine cellar conditions with temperatures maintained between 11°C and 16°C
  • Quiet in operation with an anti-vibration system with elements mounted on rubber shock absorbers
  • Power consumption is controlled by the fans on the condenser side
  • Ecological coolant gas used that does not contain CFCs
  • Dimensions of the device enable installation in cellars, attics or other underutilised areas of your home
  • Easy maintenance with a dust filter change is recommended once a year

WineMaster C50SR Specification:

  • Power supply: 10 Amp – supplied with prewired UK plug
  • Cooling volume: up to 50m³**
  • Overall dimensions: H.530 x W.552 x D.590 mm
  • Wooden frame dimensions: H.374 x W.552 X D.150 mm
  • Weight: 45 kg
  • Cooling capacity: 1200 W at 15°C **
  • Electrical power rating: 550 W
  • Sound level (at 1 m and 3 m): 51 dB / 47 dB
  • Cellar airflow rate (cold side): 400 to 500 m³/h
  • Outside airflow rate (hot side): 350 to 550 m³/h
  • Refrigerant: R407 C
  • Heating: 500 W
  • Temperature regulation: Preset to 13 °C adjustable between 11 and 16 °C**
  • Maximum operation temperature (Outdoor):  35°C**
  • Antifrost-Heating Belt: YES

** Proper insulation tailored to the cellar’s size will help lower the amount of energy consumed when operating temperatures are moderate. However, should the temperature reach 35 °C, the device may struggle to maintain a cellar temperature of 12 °C.

At Electric Ltd, we specialize in providing both electrical and refrigeration installations, with our certified and licensed engineers ensuring each component is in accordance with the necessary technical and safety regulations. We strive to make your experience with us hassle-free, serving as your one-stop contact for any issues.

If you need any help with your wine cellar installation, we’re more than willing to provide our services. Our expert assistance covers product selection, insulation guidance, unit placement, and electrical advice contact us now

Already own a Winemaster product and need a service visit?

We are here to assist you with the entire Winemaster product range, including service visits, fault finding, repairs, and replacement parts.

You can reach us via the contact form or call 020 3286 8525.
