WineMaster C25SR – Cooling, Heating and Antifrost Protection
WineMaster C25SR – Cooling, Heating and Antifrost Protection
WineMaster C25SR offers the same features as the C25S, with the added bonus of an antifrost-heating belt protector for the compressor. This belt effectively thwarts the refrigerant from solidifying in cold weather, so the machine can power up regularly. The heat generated by the belt assists in keeping the refrigerant in liquid form and ensures the unit starts without difficulty.
The features and benefits of the WineMaster C25SR Wine Conditioning Unit include:
- Reduced energy costs with an energy-saving motor compressor
- 2 adjustable speeds controlled by the thermostat
- 90% electrical efficiency with a brush-less engine
- Rubber shock absorbers for quiet operating (At 1m to 3m expect 45dB to 40dB)
- Eco-friendly with no CFCs
- Electronic thermostat with easy-to-read digital display
- Cold production can be manually stopped with a standby mode
- Easy installation with a wooden frame supplied as standard
- Low and easy maintenance will a single dust filter requiring cleaning and replacement annually
WineMaster C25SR Specification:Â
- Power supply: 5 Amp – supplied with prewired UK plug
- Cooling volume: up to 25m³**
- Overall dimensions: H.380 x W.540 x D.524 mm
- Wooden frame dimensions: H.374 x W.514 x D.150
- Weight: 31 kg
- Cooling capacity: 550 W at 15°C **
- Electrical power rating: 400 W
- Heater rating: 250 W
- Sound level (at 1 m and 3 m): 45 dB / 40 dB
- Cellar airflow rate (cold side): 96 to 198 m³/h
- Outside airflow rate (hot side): 179 m³/h
- Refrigerant: R290
- Temperature regulation: Preset to 13 °C adjustable between 11 and 16 °C**
- Maximum operation temperature (Outdoor): 35°C**
- Heating:Â YESÂ
- Antifrost-Heating Belt:Â YES
** Proper insulation tailored to the cellar’s size will help lower the amount of energy consumed when operating temperatures are moderate. However, should the temperature reach 35 °C, the device may struggle to maintain a cellar temperature of 12 °C.
At Electric Ltd, we specialize in providing both electrical and refrigeration installations, with our certified and licensed engineers ensuring each component is in accordance with the necessary technical and safety regulations. We strive to make your experience with us hassle-free, serving as your one-stop contact for any issues.
If you need any help with your wine cellar installation, we’re more than willing to provide our services. Our expert assistance covers product selection, insulation guidance, unit placement, and electrical advice contact us now
Already own a Winemaster product and need a service visit?
We are here to assist you with the entire Winemaster product range, including service visits, fault finding, repairs, and replacement parts.
You can reach us via the contact form or call 020 3286 8525.
WineMaster WINE C25SRX Conditioning Unit
The WineMaster C25SRX Provides Cellar Cooling, Heating, And Compressor Anti-Frost Features.
utilizes the newest refrigerant in its system, as denoted by the X in its name.
Share on facebook
Share on twitter
Share on linkedin
Share on whatsapp
Share on email
-
Single Point Of Contact
Our prominent attribute involves offering a singular point of contact for all aspects of project support, sales, warranty, and repairs.
-
Price Match Promise
We promise to match the price offered by any dealer.
-
Warranty
2 Years UK based warranty provided directly by us, without any involvement of third parties.
-
Reviews
Our reputation is of utmost importance. We invite you to peruse our reviews on Trustpilot to gain insight into the experiences of our customers.
- Manual
- Handy Tips
Wine Master C25 ManualÂ
When purchasing Wine Master units from Elextric Ltd, you can benefit from a product warranty, outstanding customer service, and a single point of contact for any enquiries. View/download the Wine Master C25SRX manual Here
Handy Tips Greetings, thank you for taking the time to view this section. I’m Michel, the Managing Director and Lead Engineers at Elextric Ltd, and I have chosen to share my expertise with architects, contractors, and the self-proclaimed wine connoisseurs out there. My knowledge comes from a number of years of managing environment control management projects, one of which was centred around wine storage. For your convenience, I have put together this checklist, acquired from prior assignments and accumulated years of experience, to assist in your pursuit of a flawlessly designed wine storage system.Â
– Sealed environment: When describing the importance of cellar insulation to my clients, I often use the term sealed environment. Same as a cold room or a fridge, creating a fully-enclosed area with insulated walls, ceiling, floor, and door will construct a tightly-sealed environment. I recommend using XPS insulation materials for this task.
– Wine Racking: I would recommend the racking per hole, as it allows the entire bottle to reach the ideal temperature and promotes air circulation within the cellar. Ultimately, however, the decision is up to the client.
– Unit location: Â The Winemaster is reliant upon air circulation for its function, and thus it is highly advised to locate the unit as centrally as possible.
– Water drainage: When planning for the draining of condensation water, one should keep in mind that water always follows the laws of gravity. If the pipe length is too long, a condensation pump may be used as a viable solution.
– Operation temperature: This is related to the hot side of the unit (The compressor side) where the heat exchange is happening. For example, if the heat exchange happens within a plant room or utility room and the ambient temperature exceeds 30°c, an MHRV Mechanical Heat Recovery Ventilation system must be used.
– Planning ahead is key to determining which wine conditioning unit to install. Then, design your cellar around the unit to ensure that both the electrical connection and the unit are within easy access.
I will update this section regularly based on my interactions with customers. If you have any queries or need help, please don’t hesitate to contact me through the enquiry form.
